Hotpoint Washing Machine Carbon Brushes: Role, Symptoms, and Fault Codes

What Do Carbon Brushes Do?

In Hotpoint washing machines, carbon brushes supply electricity to the motor’s rotating armature, powering the drum during wash and spin cycles. Because they’re in constant contact with moving parts, they wear down over time and need replacing to keep your machine working properly.

Signs of Worn Carbon Brushes

If your carbon brushes are worn out, you may notice:

  • The drum doesn’t turn, or spins only now and then
  • The motor sparks, or starts and stops unexpectedly
  • The machine fills and drains, but doesn’t agitate or spin
  • Unusual noises coming from the motor

These symptoms often point to worn brushes—and replacing them can restore full motor function.

How to Replace Hotpoint Carbon Brushes

  1. Unplug the machine from the mains supply.
  2. Access the motor by removing the back panel and drive belt.
  3. Remove the old brushes, noting their angle and placement.
  4. Fit new brushes in the same orientation, ensuring good contact with the motor’s commutator.
  5. Reassemble the machine and run a test cycle to check drum movement.

Related Error Codes and What They Mean

F02 – Motor Circuit Failure
Occurs when the drum doesn’t move after the programme starts. Worn brushes are the most common cause.

F30 / F31 – Motor Error
These codes often indicate faulty brushes, a broken drive belt, or issues with the motor relay or PCB.

Other Possibly Related Codes

  • F01 – Circuit Board Failure: Can sometimes appear if electrical faults arise from motor issues.
  • F03 – Temperature Sensor Fault: Not directly linked to brushes, but may show up alongside other motor-related errors.

In Summary

Worn carbon brushes are a common cause of motor failure in Hotpoint washing machines—and they’re often linked to F02, F30, and F31 fault codes. Replacing them is a simple, affordable fix that can bring your machine back to life.

Always use the correct carbon brushes for your specific Hotpoint model to ensure safe, long-lasting repairs.
